Accessories for Pixel applications

WS2812 protect
WS2812 protect
Protection circuit for WS2812-stripe and matrix systemsAt WS2812 the WS2811 is already integrated in LEDs and allows the digital controlling of pixel. Most common is the LED-stripe with WS2812. The available version WS2812B can be very sensitive to voltage peak and ESD. A small cuircuit has been developed to mostly prevent a destruction of the first pixel. A small board is linked directly infront of the first pixel. The board has been designed that a directly connection of a LED-stripe is possible. The connections has to be identical with these of the board.One aspect of the circuit is the serial resistor of 270 Ohm. If you have such a resistor already present on the LED-stripe, you can override it, if it causes difficulties in operation-
Product number: LK49p

€2.90*
range extender 5V for digital LED installations
range extender 5V for digital LED installations
When using digital LED-stripes you can usually realise cable lengths of up to 2m, since the high-frequency signal is quickly distorted and wrong colors are displayed or flickering occurs. This range-extender allows for cable lengths of up to 50m.  You need a sender PCB at the controller and a receiver PCB at the led-stripe. The mode (sender/receiver) can be set through a solder-jumper.   Technical background: The signal for digital LED-stripes is relatively low-power but high-frequency. Much data needs to be sent in a short period of time, which is no problem for small installation with short cable-lengths. But with longer cables (over 2m) especially RF-waves, power lines and other electrical devices in the vicinity can cause disturbances relatively quickly. This range extender eliminates this problem by converting to a symmetrical signal (similar to DMX-signales). Instead of sending the signal on one line, it is transmitted on two lines. One line carries the normal signal, the other is inverted. The relevant information can be read by the difference between the two lines. Since disturbances always influence both lines equally, the information can still be read by the difference between the two lines. At the end of the cable the signal is converted back to the normal format for digital LED-stripes. You always need two range-extenders, one at the bedinning and one at the end of the data-line.
Product number: LK118-5

€4.60*
range extender 12V for digital LED installations - receiver only
range extender 12V for digital LED installations - receiver only
When using digital LED stripes you can usually realize cable lengths of up to 2m, since the high-frequency signal is quickly distorted and wrong colors are displayed or flickering occurs. This range extender allows for cable lengths of up to 50m.  You need a sender PCB at the controller and a receiver PCB at the LED stripe. The mode (sender/receiver) can be set through a solder jumper. Because the 12V range extender produces heat in transmitter mode, it should only be used in receiver mode! Technical background: The signal for digital LED stripes is relatively low-power but high-frequency. Much data needs to be sent in a short period of time, which is no problem for small installation with short cable-lengths. But with longer cables (over 2m) especially RF-waves, power lines and other electrical devices in the vicinity can cause disturbances relatively quickly. This range extender eliminates this problem by converting to a symmetrical signal (similar to DMX-signales). Instead of sending the signal on one line, it is transmitted on two lines. One line carries the normal signal, the other is inverted. The relevant information can be read by the difference between the two lines. Since disturbances always influence both lines equally, the information can still be read by the difference between the two lines. At the end of the cable the signal is converted back to the normal format for digital LED-stripes. You always need two range-extenders, one at the bedinning and one at the end of the data-line.
Product number: LK118-12

€5.50*
Details
Mini USB cable 1m
Mini USB cable 1m
Standard USB cable from plug mini-B to plug A with 1m length.
Product number: LED523musb

€2.50*
