1-10V LED DRIVER

1-10V is a very simple system for remote control of lighting. The LED drivers can be connected to a standard 1-10V driver and controlled with it.

Controller lk80-21-10v_ledcontroller
1-10V LED dimmer 1-channel | 1x8A
This 1-10V dimmer is designed for 1-channel LED applications, such as dimming white LED strips. The receiver has a powerful 8 amp output and can thus operate e.g. 24V LED installations up to 192 watts! The LED dimmer works with all common 1-10V controllers and potentiometers. Scope of delivery: 1x Receiver LK80-2 Technical data: Channels: 1 Voltage: 12V-36V DCPower: Power connection via external switching power supply (not included)load: 8AConnection: input (V+/ground; 1-10V) output (1xLED channel, V+)IP class: IP 20Dimensions: LxWxH 82x33x20mm
Product number: LK80-2

€32.00*
Controller lk801-10v_ledcontroller
1-10V LED dimmer 1-channel | 4x4A
This 1-10V dimmer is designed for 1-channel LED applications, e.g. for dimming white LED strips. There are 4 outputs on the receiver, which are controlled in parallel. Each output can be loaded with 4A, which makes even very large installations feasible. The LED dimmer works with all common 1-10V controllers and potentiometers. Scope of delivery: 1x Receiver LK80 Technical data: Channels: 1 Voltage: 12V-36V DCPower: Power connection via external switching power supply (not included)Load: 4A per output portConnection: input (V+/ground; 1-10V) output (4xLED channel, V+)IP class: IP 20Dimensions: LxWxH 179x46x19mm ​Note: The driver has double voltage inputs (++--). For high connected load (> 200 Watt), use our special connection cables for high connected loads (> 200 watts) in order to divide the current load between the two inputs. The large power supplies HLG-480 and HLG-600 already have double voltage outputs, so that both voltage inputs of the driver can be used directly here.
Product number: LK80

€52.50*
Controller lk79
1-10V universal LED driver 4-channel | 4x4A
This 1-10V driver is designed for 4-channel LED applications, e.g. for controlling RGB or RGBW LED strips, but also for CCT or 4 pure white LED strips to be controlled separately. There are 4 outputs on the receiver. Each output can be loaded with 4A, which makes even very large installations feasible. The universal LED driver works with all common 0-10V and 1-10V drivers. So at the input can be connected passive 1-10V potentiometers for control (control voltage comes from the driver) as well as 0-10V industrial controllers, where the control voltage comes from the controller. Scope of delivery: 1x Receiver LK79 Technical data: Channels: 4Voltage: 12V-36V DCPower: Power connection via external switching power supply (not included)Load: 4A per output portConnection: input (V+/ground; 4 x 1-10V) output (4 x LED channel, V+)IP class: IP 20Dimensions: LxWxH 179x46x19mm ​Note: The driver has double voltage inputs (++--). For high connected load (> 200 Watt), use our special connection cables for high connected loads (> 200 watts) in order to divide the current load between the two inputs. The large power supplies HLG-480 and HLG-600 already have double voltage outputs, so that both voltage inputs of the driver can be used directly here.
Product number: LK79

€52.50*

1-10V drivers are available e.g. from all known switch manufacturers (JUNG, GIRA, MERTEN, BUSCH JÄGER etc.) as a built-in module for the flush-mounted box. These modules only need to be connected to the driver via a 2-wire cable and the light can be controlled directly on the wall. As an example, a 1-10V driver for the flush-mounted box from GIRA, model 0309 00:





The 1-10V control voltage is supplied by the driver. I.e. the 1-10V driver does not have to be connected to the mains here.

However, many drivers for the flush-mounted box can also switch 230V at the same time. This is usually done by pressing on the driver. Here, for example, the LED power supply can be switched via 230V and simultaneously dimmed via 1-10V on the LED driver with one and the same driver.

Note: 0-10V control (e.g. via SPI)

Especially in the industry there is also the alternative 0-10V control. In contrast to the classic 1-10V control, here the control voltage is not generated at the driver, but at the central control (via SPI). Our 1-10V drivers can work with both systems and are therefore also suitable for an SPI. But it is important that the SPI supplies 1 Volt as minimum voltage. Everything below 1 volt the driver interprets as if no voltage is present and then switches to the 1-10V mode where it generates the 10V control voltage itself. I.e. via SPI must always be operated between 1 and 10 volts, never below.
