SP108E LED Pixel Controller with App control

€29.00*

Available, delivery time: 3-5 days

Product number: LK126
Available stock: 16

The SP108 can drive up to 2,048 pixels and many different pixel types: WS2801, WS2811, WS2812, SK6812, APA102 and many more.

The suitable app "LED Shop" is available for free for IOS and Android and offers 180 different chase effects as well as precisely adjustable single colors. Speed and brightness can be changed at any time. A handy feature is that you can choose your favorites from the 180 effects and then quickly select them.

Setting up the driver is quite intuitive and done in a few minutes. The driver works in the 2.4 GHz WLAN and can be accessed directly via the smartphone as well as integrated into the home WLAN.



Screenshots of the App:

SP108 App



The scope of delivery includes:

  • 1 x LED driver SP108E
  • 1 x 3-pin connection cable for LED strips
  • 1 x mini screwdriver



Supported LED types:

  • WS2801, WS2811, WS2812
  • SK6812, SK6812_RGBW, SK9822
  • APA102, APA105
  • TM1804, TM1814, TM1913, TM1914, TX1812, TX1813
  • LPD6803, LPD8806
  • P9813, P943S, P9411, P9412, P9413, P9414
  • GS8206, GS8208
  • SM16703, UCS1903, INK1003, DMX512



FAQ:

Does the driver require an existing WLAN?

No, the driver can also be controlled directly with the smartphone (AP mode) and offers its own WLAN access point ("SP108E_xxx") for this purpose. If a WLAN is available, the driver can alternatively be integrated into it (STA mode), so that the WLAN does not always have to be changed to operate the driver.

Can multiple drivers be used simultaneously in the app?

Yes, the app can manage multiple drivers at the same time. You can switch between the drivers and change the settings for each. In addition, the individual drivers can be switched on and off directly. However, there is no direct synchronization and each driver must be set accordingly for itself.

Does the app have to be active for the animations to run?

No. The app is only needed for the setup. You can close the app afterwards and also turn off the smartphone, for example. The SP108 will continue to play effects.

Does the driver keep its settings when it no longer receives power?

Yes, the driver can simply be disconnected from the mains. When power is applied again, it will start with the previously set animation. All settings will be kept.

How can the white LEDs be used, e.g. with a SK6812_RGBW?

The app has a separate control for white LEDs (e.g. for SK6812_RGBW pixel strips). This can be used to set the proportion of white LEDs and then, in the case of effects, the white LEDs are taken into account accordingly, so that the colors are generally desaturated. In the effects section of the app, the SOLID setting can then also be used to activate a permanently white, high-quality light, e.g. for lighting tasks, if required.

Can the SP108 also control LED matrices?

A number of pixels and a number of segments can be set in the setup. For example, for an 8 x 8 matrix then 8 pixels and 8 segments. This is taken into account in the effects, but in most matrices the pixels are connected in a snake shape as a long line and this is unfortunately not taken into account by the SP108. Therefore the effects are not displayed as desired on the matrix, but every 2nd row of the matrix shows the effect quasi upside down. We hope for a technical improvement here soon.



Technical data:

  • Input: 5-24V DC, GND
  • Output: VCC, GND, Data, Clock
  • current consumption: approx. 90mA
  • up to 2.048 pixels depending on IC type
  • ambient temperature: -20°C - +60°C
  • dimensions: 80x41x20mm
  • Weight: 40g
